Mini-Track · mini magnetic track for display cases · 24V

Showcase lighting without the pole.

A 14 mm recessed magnetic track replaces the light poles in a display case. Heads slide, rotate and aim as the display changes. Jewelry, watches, cards, collectibles, eyewear, phones.

Request a free sample → See the system

No poles on the deckTrack in the side wall or top rail. Deck clear.
Slide, rotate, aimMagnetic heads, any point, either way round.
14 mm wide12 × 12 mm groove; the flange reads as cabinet frame.
Color temperature to order3000K or 4000K most specified. 24V, dimmable.

Mini-Track · display shelving, a spot in every bay

14 mmTrack width · 9/16 in

0Poles on the deck

4Head types on one track

3000K / 4000KMost specified · CCT to order

24VDC · Class 2

Mini-Trackdisplay case system · 24V

Remove the pole. Keep the flexibility. Put the focus back on the product. Adjustable light that is not furniture.

01
Remove the pole
No rods, no bases among the goods. Track in a 12 × 12 mm groove; deck clear edge to edge.
02
Keep the flexibility
Heads slide, rotate, tilt and swap between spot, micro spot, bar and strip. A new display takes minutes.
03
Focus on the product
Crossed spots on the hero piece, tight pools on the trays, a soft strip at the back. Goods, not lighting.

Before · after

The pole is the part the customer should never notice.

Same case, same goods, same spots. Only the hardware moves.

Before · pole-mounted spots

Four rods, four bases, four heads in the display

1Rods stand between the customer and the goods.
2Bases take deck space from stands, trays and props.
3Fixed heads. A new layout means new holes.

After · Mini-Track

Track in the side walls, heads at the edge, deck clear

114 mm track in each side panel, frame color. Reads as a cabinet detail.
2Heads at the wall, aimed in. Slide, rotate, tilt, swap.
3Whole deck is display. Side light gives small objects shape.

The system

One track. Ten parts. Any length, any layout.

24V track, powered along its length. Heads pick it up anywhere. Connectors turn corners and join lengths.

1
Input connectorMT-IN · feed from the 24V driver
2
Sensor inputMT-IN-S · hand-wave sensor, 3–8 cm range, switches the case
3
Linear spot barMT-SP-L · 7 W, eight lenses
4
Aimable spotMT-SP-A · 1.2 W, rotates and tilts
5
Flat 90° cornerMT-CR-F · turns in the same plane
6
Recessed trackMT-TK · 14 × 12 mm, three-conductor, 3 m sections cut to order
7
Strip moduleMT-ST · 3.05 W / ft, no dark spots
8
In-line joinerMT-JN · joins two lengths, 180°
9
End capMT-EC · closes the open end
10
90° corner, adjacent faceMT-CR-V · top rail down a side panel

Scroll sideways to see the whole path.

1
24V DC driverPower Core 36 / 60 / 96 W, or any 24V DC Class 2 supply
2
Input connectorMT-IN · feeds the track
3
Headsslide to any point, either way round, swap without tools
4
Track in the top rail3 m sections cut to order, joined in line · 3 A per run
5
End capMT-EC · closes the open end
6
Hand-wave sensor inputMT-IN-S · wave a hand 3–8 cm from it to switch

Power. Three-conductor, no polarity. 24V DC, up to 3 A (72 W) per feed. Power Core 36 / 60 / 96 W recommended, six runs each. Not shown: corners, joiner and the MT-CL installation clips.

The heads

Four heads. Drawn at the same scale.

Same track, no tools. Pick by what is displayed.

1.2 W

Aimable spot

MT-SP-A

Spot on a stalk. Rotates and tilts onto the piece.

Hero pieces on stands, watch cushions, graded cards and figures.

L46 × W10 × H49 mm
1 13/16 × 3/8 × 1 15/16 in

1 W

Micro spot

MT-SP-M

Lowest head. Fixed pool, almost flush with the track.

Ring trays, pins, coins, dice, any tray of small flat goods.

L30 × W18 × H25.8 mm
1 3/16 × 11/16 × 1 in

7 W

Linear spot bar

MT-SP-L

Eight lenses in a 4 5/8 in bar. Even coverage across a bay.

Counter showcases, eyewear, perfume, phones, rows of slabs, full bays.

L117 × W14 × H10.4 mm
4 5/8 × 9/16 × 7/16 in

3.05 W / ft (10 W / m)

Strip module

MT-ST

Diffused strip on the same track. No dark spots.

Shelf edges, back panels, soft fill against hard shadows.

L × W14 × H9.3 mm
L × 9/16 × 3/8 in

Every head, every track

UL · CE · RoHSlisted
24V DCClass 2 · 3 A per run
Magneticpolarity-free, tool-free
CCT to order3000K / 4000K usual
Dimmableon the 24V side
50,000 hrated life
3-yearwarranty

Finish: titanium gray; other finishes to order. Shelf-display rail is coffee brown. Sizes are catalog dimensions. Track ships in 3 m sections, cut to your length.

Placement guide

Three showcase types. Where the track and heads go.

Table below: what is displayed, which head, how to aim.

Tall vitrine · jewelry, collectibles

1Vertical track recessed in both side panelsMT-TK
2Aimable spots crossed on the hero piece from two sidesMT-SP-A
3Micro spots onto the traysMT-SP-M
4Input connector at the top, cable in the frameMT-IN
5Driver in the plinthPower Core

Low counter · watches, cards, phones

1Track in the top rear rail, out of the customer's sightlineMT-TK
2Spots over each cushion, tilted off the customer's eyeMT-SP-A
3Linear bar for the flat tray at the endMT-SP-L
4Corner turns the run down the end panelMT-CR-V

Wall shelving · display

1Vertical power rail in the side panel, 14 × 8.2 mmMT-VR
2Sliding connector feeds a shelf at any heightMT-VR-C
3Shelf light under each shelf, cables hiddenshelf light
4One driver at the topPower Core

What is displayed	Head	How to aim it
Hero piece on a stand: necklace bust, figure, sneaker, sealed box	Aimable spot × 2 MT-SP-A	One from each side, above eye level, crossed on the piece.
Trays of small pieces: rings, pins, coins, dice, singles	Micro spot MT-SP-M	One pool per tray, from just above the tray edge.
Watches on cushions	Aimable spot MT-SP-A	Over the cushion, tilted until the crystal's reflection misses the customer.
Graded cards, slabs, boxed collectibles	Linear bar or aimable spot MT-SP-L · MT-SP-A	Slabs reflect like crystals. Steep angle from the top rail; a bar covers a row.
Flat trays and loose product: bracelets, accessories, packs	Linear bar or strip MT-SP-L · MT-ST	Even light from two directions; single-source shadows look dusty.
Eyewear, perfume, phones, small leather	Linear bar MT-SP-L	One bar per bay, aimed at the back third of the shelf.
Full shelf bays	Strip MT-ST	Along the front edge of the shelf above. Add a spot for the hero piece.

3000K · warmGold, warm gemstones, leather, wood, vintage.

4000K · whiteDiamonds, silver, steel, cards, packaging, electronics, eyewear. Other CCTs to order.

Full drawings, groove dimensions and part list for Mini-Track, the shelf-display rail, drivers and sensors.PDF by email. New products and trade programs a few times a year. Unsubscribe anytime.

Specifications

One electrical spec for the whole set.

Input: 24V DC · any Class 2 supply · Power Core recommended
Track: Recessed, 14 × 12 mm (9/16 × 1/2 in) · 3 m (9.84 ft) sections, cut to order, joined in line
Groove: 12 × 12 mm (15/32 × 15/32 in) · 14 mm flange on the face · installation clips
Track rating: 3 A · 72 W per feed · three-conductor, no polarity · phosphor bronze
Light output: Varies by head type · see the catalog or ask sales
Heads: Aimable spot 1.2 W · micro spot 1 W · linear bar 7 W · strip 3.05 W / ft
Color temperature: To order per project · 3000K and 4000K most specified
Dimming: 24V side: dimmable driver or hand-wave controller · wall dimmer if your driver supports it
Feed: MT-IN plain input · MT-IN-S input with hand-wave sensor, 3–8 cm range

Connectors: 180° in-line · 90° flat corner · 90° onto the adjacent face
Head mounting: Magnetic, tool-free · slide to any point · swap between types
Finish: Titanium gray, other finishes to order · coffee brown (shelf-display rail)
Shelf-display rail: MT-VR · 14 × 8.2 mm · 24V · 5 A · groove 12 × 8.5 mm or surface bracket · connector MT-VR-C, 3 A
Location: IP20 · indoor, dry · inside closed or open display cabinets
Driver sizing: Head watts ≤ 80% of driver rating · 36 / 60 / 96 W · six runs per driver
Listing · life · warranty: UL · CE · RoHS · 50,000 h rated life · 3-year warranty

UL24V DC14 MM TRACKIP20CCT TO ORDERDIMMABLEMAGNETIC

Parts and dimensions
Model	Part	mm	in	Note
MT-TK	Recessed track	3000 × W14 × H12 mm	9.84 ft × 9/16 × 1/2 in	3 m sections, cut to order, joined in line. 3 A per run.
MT-IN	Input connector	L36.8 × W14 × H11.9 mm	1 7/16 × 9/16 × 1/2 in	Feed from the 24V driver.
MT-IN-S	Input connector with hand-wave sensor	L51.3 × W14 × H12 mm	2 × 9/16 × 1/2 in	Wave a hand 3–8 cm from the sensor to switch the case.
MT-SP-A	Spot, aimable	L46 × W10 × H49 mm	1 13/16 × 3/8 × 1 15/16 in	1.2 W
MT-SP-M	Spot, micro	L30 × W18 × H25.8 mm	1 3/16 × 11/16 × 1 in	1 W
MT-SP-L	Spot, linear bar	L117 × W14 × H10.4 mm	4 5/8 × 9/16 × 7/16 in	7 W
MT-ST	Strip module	L × W14 × H9.3 mm	L × 9/16 × 3/8 in	3.05 W / ft
MT-JN	180° in-line joiner	L57 × W14 × H7.8 mm	2 1/4 × 9/16 × 5/16 in	Joins two straight lengths.
MT-CR-F	90° flat corner	L42 × W42 × H12 mm	1 5/8 × 1 5/8 × 1/2 in	Turns the run in the same plane.
MT-CR-V	90° corner, adjacent face	L36.2 × W36.2 × H10 mm	1 7/16 × 1 7/16 × 3/8 in	Top rail down a side panel.
MT-EC	End cap	L15.5 × W14 × H12 mm	5/8 × 9/16 × 1/2 in	Closes the open end.
MT-CL	Installation clip	L25 × W13 mm	1 × 1/2 in	Fixes the track in its groove.
MT-VR	Shelf-display power rail	L × W14 × H8.2 mm	L × 9/16 × 5/16 in	Vertical rail, 24V, 5 A, coffee brown. 12 × 8.5 mm groove or surface bracket.
MT-VR-C	Sliding rail connector	L25 × W14 × H7 mm	1 × 9/16 × 1/4 in	Feeds a shelf at any height.

Load planner

Enter the case. Get the parts list and the driver size.

Planning list. Paste it into the quote request; we confirm the bill of materials within 24 hours.

Parts list

Connected load

Request this as a quote →

Priced per project. Clips, dimmers and cables added at quote.

Applications

Built for the people who build showcases.

Retailers selling small goods from a case, and the showcase builders who supply them.

Retail display shelvingTrack in each bay

Shelf display, hidden cablesVertical rail · shelf light at any height

Wardrobe and closet shelvingRail in the side panel

Jewelry, watches, gold and diamondsVitrines, wall cases, window displays that change weekly.
Trading cards, collectibles, comics, gamesSlabs, sealed product and figures behind glass.
Eyewear, perfume, beauty, phones and accessoriesOpen bays and glass shelving with small, high-value goods.
Museum shops, hobby, gift and heritage displayModels, minerals, coins and gifts.
Showcase manufacturers and store fixture shopsOne groove spec, one part list, any case size.

Mini-Track shelf display, cables hidden in the side panel

How to order

Send the case dimensions. Seat what comes back.

01
Send the case
Drawing, spreadsheet or photo with inside dimensions. Say what is displayed and where the track goes.
02
Quote, usually within 24 hours
Track, heads, corners, input and driver per case. Trade pricing applied. Custom CCT or finish takes longer.
03
Cut, packed per case, shipped
Cut and labeled to the case. On site: clip in, connect, seat the heads.

Start a quote →Talk to the team

Warranty & support

Three years. Swap a head, not the case.

Three-year warranty on track, heads, connectors and drivers. A service call swaps one head; the cabinet is untouched.

Layout or wiring question? Our US-based team answers at sales@leonlite.com.

FAQ

Questions showcase builders ask first.

How do the heads attach to the track?

Magnetically; 24V comes from the rail. No polarity, so either way round. Slide, rotate, tilt or swap. No tools.

Can I add or move heads after the showcase is built?

Yes. Power runs the whole length, so heads move, add or remove whenever the display changes.

What does the cabinet need?

A 12 × 12 mm groove (15/32 in) in the side panel, top rail or frame. Track drops in, flange on the face, clips hold it. All-glass cases: top rail or corner post.

Which power supply?

Any 24V DC Class 2 supply. Power Core recommended: 36 / 60 / 96 W, six runs each. MT-IN-S input adds hand-wave switching, 3–8 cm range.

How many heads will one driver run?

Add the head watts: 1.2 W spot, 1 W micro spot, 7 W bar, 3.05 W per foot of strip. Keep under 80% of driver rating and 72 W (3 A) per feed. The planner does the arithmetic.

Is it dimmable?

Yes, on the 24V side: dimmable driver or hand-wave controller. Wall dimmer as long as your driver supports it.

Which color temperature?

To order. Most specify 3000K (gold, leather, warm stones) or 4000K (diamonds, silver, cards, electronics).

How do I turn a corner or run down a side wall?

MT-CR-F: 90° in the same plane. MT-CR-V: onto the adjacent face. MT-JN: joins two lengths in line.

Is there a minimum order?

No. One case or a full fit-out. Track by the length, heads by the piece.

How long does a quote take?

Usually within 24 hours. Custom color temperature or finish takes longer: we confirm it with the factory first.
